MatrixPRO-II 3G/HD/SD-SDI Routers Rev. 1.1
MatrixPRO-II HD/3G SDI Series –User’s Guide - Rev. 1.1
30
B.1 X-Point Take
This command directly takes the specified X-point. The command specifies which sources to
connect to which destinations and on what levels. Several X-point takes can be specified on
a single command line. In such cases all specified X-points are taken simultaneously.
Command:
x [ : ][*CC]
Response:
%
x l
[*CC]
Where:
=[ ]
=l
=[ ]
=
={|,|-}
={|,|-}
The level number.
Source number in the range from zero to one less than the number of inputs
on the level. can also be one of the following characters:
d
Disconnect. Used when a destination is not connected to any source.
o Out of range. Used when a destination is connected to a source not
included in a level. This may occur with overlapping partitions. Only
valid in the response.
u Undefined/Unknown. This might be used at start-up before the status
is read from the physical router. It is also used on ported routers
where a port can be used as an input or an output. Only valid in the
response.
Destination number in the range from zero to one less than the number of
outputs on the level.
