Bryston BR2 User Manual
Page 3
PROGRAMMING THE BCD-1 via the BR2 REMOTE CONTROL:
Press the CODE button on the remote control until the red LED lights and then enter the 3 digt code as listed below. The LED
will flash to confirm transmission and then extinguish.
242: To enable toggling the display ON or OFF. After entering code 242 the zero button can be used to toggle the
display on or off. Reverse this procedure to deactivate this display on/off function
Enable or disable the External (remote) Trigger:
1st) Place the BCD-1 in standby mode by pressing the POWER button on either the BCD-1 itself or on the remote
control until the red standby LED on the front panel of the BCD-1 (immediately above the front panel POWER
button) lights.
2nd) Press the CODE button momentarily until the red LED is continuously lit.
3rd) Enter the code 241. Every time the code is successfully entered the state of the External Trigger will toggle
between enabled and disabled and the status of the External Trigger will be displayed on the alpha-numeric
display for 2 to 3 seconds.
The External Trigger utilizes a control voltage (3 to 12 volts, either AC or DC) connected to the TRIGGER IN
port on the rear of the BCD-1. A wire-clamp connector that mates with the TRIGGER IN port is provided with
every BCD-1 (See page 2 for wiring details). Once enabled the BCD-1 will only be powered on when a control
voltage of 3-12V AC/DC at ≥3mA is present. As soon as the control voltage is withdrawn the BCD-1 will power
down and go into standby mode.
For more information see the BCD-1 Owners Manual
PROGRAMMING THE BDA-1 via the BR2 REMOTE CONTROL:
Press the CODE button on the remote control until the red LED lights and then enter the 3 digt code as listed below. The LED
will flash to confirm transmission and then extinguish.
021: source OPTO-1
026: source SPDIF-4
250: Output level 0dB
022: source OPTO-2
027: source AES/EBU
251: Output level -1dB
023: source SPDIF-1
028: source USB
252: Output level -2dB
024: source SPDIF-2
029: Power ON/OFF
253: Output level -3dB
025: source SPDIF-3
030: Upsampling ON/OFF
Codes 021 thourgh 030 mimic the actions of the corresponding dedicated buttons on the BR2. These codes can also be
sent to the BDA-1 via the RS232 control port to facilitate the use of system controllers such as those provided by AVX,
Crestron, etc.
For more information see the BDA-1 Owners Manual
IMPORTANT SAFETY INSTRUCTIONS:
Thelightningflashwitharrowheadsymbolwithinanequilateraltriangle,isintendedtoalerttheusertothepresenceofun-insulated“dangerousvoltage“
withintheproduct’senclosurethatmaybeofsufficientmagnitudetoconstituteariskofelectricshocktopersons.
Theexclamationpointwithinanequilateraltriangleisintendedtoalerttheusertothepresenceofimportantoperatingandmaintenance(servicing)
instructionsintheliteratureaccompanyingtheproduct.
1.Readtheseinstructions.
2.Keeptheseinstructions.
3.
Heedallwarnings.
4.Followallinstructions.
5.
Donotusethisapparatusnearwater.
6.
Cleanonlywithdrycloth.
7.
Donotuseorstorenearanyheatsourcessuchasradiators,heatregisters,stoves,orotherapparatus(includingamplifiers)thatproduceheat.
8.
Referallservicingtoqualifiedservicepersonnel.Servicingisrequiredwhentheapparatushasbeendamagedinanyway,suchaspower-supplycord
orplugisdamaged,liquidhasbeenspilledorobjectshavefallenintotheapparatus,theapparatushasbeenexposedtorainormoisture,doesnot
operatenormally,orhasbeendropped.
WARNING:TOREDUCETHERISKOFFIREORELECTRICSHOCK,DONOTEXPOSETHISAPPARATUSTORAINORMOISTURE.
DONOTEXPOSETHISEQUIPMENTTODRIPPINGORSPLASHINGANDENSURETHATNOOBJECTSFILLEDWITHLIQUIDS,SUCHASVASES,AREPLACED
ONTHEEQUIPMENT.
