CHASSIS PARTS
4
For Models: WFC340S0AW0, WFC340S0AB0, WFC340S0AS0
(White) (Black) (Stainless)
W10489549
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10393499 Vent Tube
2 W10387238 Box, Burner
3
Panel, Side
W10322769 White
W10322770 Black
4
3196548 Fuse, Thermal
5
8522416 Seal, Oven Door
6 W10308476 Element, Broil
7 W10312465 Element, Bake
8 W10181986 Sensor
9 W10317898 Glide, Drawer Frnt
10 W10341186 Foot, Front
11 W10067840 Screw
12 W10312471 Tray, Insulation
13 W10137382 Clip, Panel
14
Assy, Rail Base
W10390007 Left
W10390008 Right
15 W10058460 Foot, Rear
16 W10289077 Hinge, Reciever
17 W10355173 Bracket,
Oven Support
18
3186034 Bracket, Service
19 W10245259 Block, Terminal
20 W10224919 Back, Main
21
3196567 Screw
22
3196168 Screw
23
3196174 Screw
24
3196169 Screw
25
9757238 Switch, Door
26
3196178 Screw
27
3400016 Screw
28 W10031780 Screw
29
3196701 Light Socket Assy
30
311255 Bulb, Oven Light
31
7103P027−60 Nut
32 W10326122 Cover,
Terminal Box
33
9761448 Retainer, RH
34
9761449 Retainer, LH
35 W10281322 Kit, Bare Wire
36 W10451176 Suppressor
37
3196172 Screw
38
3196560 Screw
39
9761013 Assy, Door Latch
(Front)
40 W10107830 Assy, Door Latch
(Rear)
41
8523249 Brkt, Manifold
42 W10078370 Rod, Push
(Latch)
43
9757239 Rod, Door Switch
(Rear Mount)
44 W10391967 Deflector, Air
45 W10316861 Box, Burner
(Gas)
46
W10312473 Shield, Heat
INSULATION
W10393501 Insulation, Wrap
8272612 Insulation, Back
