DISPENSER PARTS
6
For Models: WFW96HEAW0, WFW96HEAC0, WFW96HEAU0
(White) (Chrome Shadow) (Stainless)
W10519569
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10247306 Valve, Inlet
2 W10239949 Hose, Inlet Valve
To Active Vent
3 W10096852 Clamp, Hose
4
8181696 Flowmeter
5 W10239955 Hose, Inlet Valve
To Flowmeter
6 8183181 Nozzle, Inlet
7 8183183 Lever, Connection
8 W10003190 Cam, Actuator
9 W10292700 Clamp, Hose
10 W10163975 Actuator
11
8540282 Screw
12 W10368769 Housing, Minibulk
Dispenser Assembly
13 W10003110 Nozzle,
Distribution
14 W10306690 Sensor, Magnetic
Angular
15 W10250743 Dispenser,
Minibulk Cartridge
16 W10256661 Siphon,
Bleach/Softener
17 W10003140 Cover,
Detergent Drawer
18 W10250723 Drawer, Detergent
19 W10239956 Hose, Flowmeter
20
Handle, Drawer
W10446403 White
W10446405 Chrome Shadow
W10502248 Silver
21 W10387117 Badge
22 W10239910 Clamp, Hose
23 W10239966 Hose, Dispenser
To Bellow
24 W10250730 Tube, Siphon
Minibulk Dock
25 W10250731 O−Ring
26 W10376678 Washer,
Siphon Tube
27 W10268381 Hose, Tube To Pump
28 W10250734 Pump, Metering
29 W10096851 Clamp, Hose
30 W10268382 Hose, Pump
To Dispenser
31 W10239942 Valve, Diverter
32 W10239935 Hose, Inlet
33 W10239908 Hose, Spray
Assembly
