TOP AND CABINET PARTS
2
For Models: WFW96HEAW0, WFW96HEAC0, WFW96HEAU0
(White) (Chrome Shadow) (Stainless)
W10519569
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10441093 Installation
Instructions
W10441096 Use & Care Guide
W10441104 Tech Sheet
W10441098 Energy Guide
2 Top
W10208373 White
W10460693 Chrome Shadow
W10316283 Silver
3 Cabinet
W10441110 White
W10441105 Chrome Shadow
W10441107 Silver
4 Panel, Front
W10441116 White
W10441111 Chrome Shadow
W10460695 Silver
5 W10237503 Retainer, Bellow
To Front Panel
6 8183197 Lock,Door
7 8540282 Screw
8 W10001130 Foot, Leveling
9 W10339879 Cable Tie
10 W10498561 Harness, Wiring
(Lower Main)
11 W10374126 Motor Control Unit
12 W10271590 Bolt, Shipping
(Set Of 4)
13 W10237498 Brace, Transport
14 W10237492 Panel, Rear
15 W10142290 Screw
16 W10467483 Brace, Rear
17
3359452 Nut, Locking
18 W10181028 Clip, Pressure
Switch Hose
19 W10367632 Filter,
Interference
20 W10448876 Sensor, Pressure
21 W10251962 Hose, Pressure
Switch
22 W10245452 Retainer, Spring
23 W10467484 Brace, Top
24
356138 Clamp, Hose
25 W10280024 U−Bend,
Drain Hose
26 W10267638 Hose, Drain
(External)
27 W10434975 Cord, Power
28
3351614 Screw
29 W10275820 Cover, Power Cord−
Transport
30 8182700 Cover, Transport
31 W10208380 Screw,
Bush Assembly
32 W10304004 Cover, Power Cord
33 W10323182 Spacer,
Front Panel
34 W10388229 Control Board,
Expansion
