Control panel and latch parts – Whirlpool WDP350PAAB User Manual
Page 5
CONTROL PANEL AND LATCH PARTS
Illus.
No.
Part No.
Description
1
Console Assembly
W10506225 Black
W10506226 White
2
W10401190 Box, Connector
3
Handle, Latch
8534984
Black
8534985
White
4
W10274884 Bolt, Latch
5
W10348413 Screw, Door
6
8524472
Actuator, Latch
7
W10375804 Control, Electronic
8
W10372484 Brace, Connector
9
W10274880 Switch, Door
10
W10274840 Button Tree
11
W10274836 Light Pipe
20121015
5
Part No. W10551272 Rev. A
