CABINET PARTS

Illus.

No.

Part No.

Description

1

Shell Assembly
(Includes Items 4,
10 & 21)

W10356268 Black

W10356269 White

2

W10506237 Coupler, Hose

Assembly

3

3400892

Screw

4

3378109

Saddle, Hose

5

Shroud, Caster

W10270163 Black

W10270155 White

6

371505

Clamp, Hose

7

6-013783

Washer

8

W10219673 Housing, Hose

9

W10496105 Power Cord

10

W10219682 Protector, Edge

Divider

11

3373329

Screw

12

3371644

Screw

13

3370826

Screw

14

3373199

Panel, Top

15

304428

Screw

16

302251

Screw

17

8559932

Casteer

18

W10254672 Adapter, Faucet

19

W10213953 Screw

20

8559928

Frame, Assembly

21

W10254751 Protector, Edge Short

22

W10328716 Bar, Blocker

23

W10001330 Screw

20121015

25

Part No. W10551272 Rev. A
