1

MOTOR AND DRIVE PARTS

For Models: GC900QPPQ0, GC900QPPB0

(White) (Black)

12−04 Litho In U.S.A. (ebk)

Part No. 882765

TRASH

COMPACTOR

Illus. Part

No. No. DESCRIPTION

1

Literature Parts

9871676 Use & Care Guide
9871765 Tech Sheet
8052029 Label, 1−800

Number

677821 Do−It−Yourself

Manual

2

9870343 Motor, Drive

(Includes Item 13)

3

9871067 Screw,

4

776327 Plate, Motor

5

776338 Locknut, 10−32 (4)

6

4149667 Gear, Drive

7

454512 Pin, Slotted

Spring

8

776035 Washer, Wave

9

297462 Washer, Thrust

10

777124 Gear, Driven

11

776036 Clip, Ring

12

780477 Chain, Drive

13

777971 Switch, Motor

Parts Not Illustrated and

Optional Parts (Not Included)

9870118 Undercounter

Conversion Kit
