DOOR PARTS

Illus.

No.

Part No.

Description

1

W10193001 Frame, Door Front

2

W10193025 Glass, Door

3

W10193034 Screw

4

W10193022 Support, Door-Back

6

W10196351 Plate, Door Lock

(Lower)

7

W10196350 Plate, Door Lock

(Upper)

8

W10196352 Washer, Clamp (Door

Safety)

9

W10196353 Spring, (Door Safety)

10

W10196349 Plug

11

W10192947 Shaft, Door-Lock

12

W10193026 Latch, Hook

Door-Lock

13

W10193049 Spring, Door-Lock

14

W10193032 Handle

15

W10193035 Screw, Door Switch

16

W10192995 Lock, Door

17

W10192994 Switch, Door

20120913

9

Part No. W10544334 Rev. A
