TUB AND BASKET PARTS
Illus.
No. Part No. Description
1 W10192997 Hose, Vent
2 W10192996 Tube, Vent
3 W10192999 Clamp, Tube Vent
4 W10193039 Clamp, Hose
5 W10193000 Spring, Tube Vent
6 W10193093 Screw, Short
(Counterweight)
7 W10193094 Screw, Long
(Counterweight)
8 W10193096 Washer,
Counterweight
9 W10192952 Counterweight (Upper)
10 W10193044 Clamp-Wire, Bellow
(Panel)
11 W10193056 Bellow
12 W10193090 Clamp-Wire, Bellow
(Tub)
13 W10192989 Bracket, NTC
14 W10193047 Air-Trap, Assembly
15 W10192949 O-Ring, Air-Trap
16 W10192945 Screw, Air-Trap
17 W10192959 Tub-Outer, Front
18 W10193053 Clamp. Tub-Outer
19 W10193092 Screw, Lower
Counterweight
20 W10192954 Counterweight (Lower)
21 W10192953 Basket, Assembly
22 W10192974 Hose, Tub-to-Pump
23 W10192948 Clamp, Hose-Pump
24 W10193033 Ball, ECO
25 W10193101 Clamp, Hose-to-Tub
26 W10193115 Nut, ECO Flange
27 W10192987 Motor
28 W10193095 Screw, Motor
29 W10192983 Tie, Wire (Motor)
30 W10192960 Tub-Outer, Rear
31 W10192964 Shock Absorber
(Dampner)
32 W10193028 Bracket, Mount
(Shock)
33 W10193058 Pulley
Illus.
No. Part No. Description
34 W10192984 Belt, Drive
35 W10192946 Nut, Pulley
20120913 11 Part No. W10544334 Rev. A
