Neff S72T69X3GB User Manual
Neff Washers
Table of contents
Document Outline
- 8 Intended use
- Intended use
- ( Safety instructions
- Delivery
- 1. Check the packaging and dishwasher immediately for damage caused in transit. Do not switch on a damaged appliance, but contact your supplier.
- 2. Please dispose of the packaging material in an environmentally friendly manner.
- 3. Do not let children play with packaging and its parts. There is a risk of suffocation from collapsible boxes and film.
- Installation
- In daily use
- Childproof lock (door lock)Door lock *
- Damage
- Disposal
- ■ To prevent injuries, e.g. caused by stumbling, open the dishwasher only briefly in order to load and unload the dishwasher.
- ■ Knives and other utensils with sharp points must be placed horizontally in the cutlery drawer.
- ■ Do not lean or sit on the open door.
- ■ In the case of free-standing appliances, ensure that the baskets are not overloaded.
- ■ If the appliance is not in a cavity and a side panel is accessible, the door hinge area must be covered at the side for reasons of safety (risk of injury). The covers are available as optional accessories from customer service or specialist outlets.
- ■ If fitted, use the childproof lock. An exact description can be found in the back of the enve lope.
- ■ Do not allow children to play with or operate the appliance.
- ■ Keep children away from detergents and rinse aid. These may cause chemical burns in the mouth, throat and eyes or asphyxiation.
- ■ Keep children away from open dishwasher. The water in the rinsing compartment is not drinking water and could contain detergent residue.
- ■ Ensure that children do not place fingers in the tablet collecting tray 1B. Small fingers could become caught in the slots.
- ■ When opening and closing the door on an eye-level appliance, ensure that children do not become jammed or crushed between the appliance door and the cupboard door below.
- ■ Children could become locked in the appliance (danger of suffocation) or get into another dangerous situation.
- 7 Protection of the environment
- * Getting to know your appliance
- + Water softening system/Special salt
- Water softening system/Special salt
- Setting
- 1. Find out about the hardness value of your tap water. Your water utility company will help you with this.
- 2. Set value can be found in the water hardness table.
- 3. Open the door.
- 4. Switch on ON/OFF switch (.
- 5. Hold down programme button # and press START button )" until •:‹.... is indicated on the digital display.
- 6. Release both buttons.
- To change the setting:
- Water hardness table
- Using special salt
- Using detergents with salt componentDetergents with salt component
- Switching off salt refill indicator/water softening systemSwitching off water softening system
- , Rinse aid
- Rinse aid
- Setting amount of rinse aid
- Switching off rinse aid refill indicator
- - Utensils
- Utensils
- Not suitable
- Glass and utensil damage
- Loading the dishwasher
- Unloading the dishwasher
- Cups and glasses
- Pans
- Cutlery drawer
- Folding spikesFolding spikes *
- Small accessories holder *Small accessories holder
- Adjusting the height of the basket
- Appliance height 81.5 cm
- 16 cm
- 30 cm
- 18.5 cm
- 27.5 cm
- 21 cm
- 25 cm
- 18 cm
- 33 cm
- 20.5 cm
- 30.5 cm
- 23 cm
- 28 cm
- 1. Pull out the top basket 12 out.
- 2. To lower the basket, press in the left and then the right lever on the outside of the basket. In doing so, hold the sides of the basket along the upper edge to prevent it from suddenly dropping.
- 3. To raise the basket, hold the basket on the sides of the upper edge and lift it up.
- 4. Before re-inserting the basket again, ensure that it is at the same height on both sides. Otherwise, the appliance door cannot be closed and the upper spray arm will not be connected to the water circuit.
- . Detergent
- / Overview of programmes
- Overview of programmes
- The max. possible number of programmes is illustrated in this overview. The corresponding programmes and their arrangement can be found on the fascia.
- Programme selection
- Information for test institutes
- 0 Additional options
- 1 Operating the appliance
- Operating the appliance
- Programme data
- Aqua sensorAqua sensor *
- Switching on the appliance
- Optical display while the programme is runningOptical display while the programme is running *
- Remaining running time display
- Timer programming
- 1. Open the door.
- 2. Switch on ON/OFF switch (.
- 3. Press the button ` + until ‹‚ is flaching in the timer programming display X.
- 4. Press + or – button until the ` displayed time corresponds with your requirements.
- 5. Press START button )", timer programming is activated.
- 6. To delete timer programming `, press the + or – button until ‹‹ is indicated on the digital display X.
- 7. Close the door.
- End of programme
- Automatic switch off after end of programme or interior light*Automatic switch off / interior light
- Switching off the appliance
- Interrupting the programme
- Terminating the programmeTerminating the programme (Reset)
- Changing the programme
- Intensive drying
- 2 Cleaning and maintenance
- Cleaning and maintenance
- Overall condition of the machine
- Special salt and rinse aid
- Filters
- 1. After each washing cycle check the filters for residue.
- 2. Unscrew filter cylinder as illustrated and take out filter system.
- 3. Remove any residue and clean filters under running water.
- 4. Re-install filter system in reverse sequence and ensure that the arrow marks are opposite each other after closing the filter system.
- Spray arms
- 3 Fault, what to do?
- Fault, what to do?
- Note
- Waste water pump
- m Warning
- Risk of cuts!
- 1. First always disconnect the appliance from the power supply.
- 2. Take out top basket 12 and bottom basket 1b.
- 3. Remove the filters 1Z.
- 4. Scoop out water, use a sponge if required.
- 5. Prise out the white pump cover (as illustrated) using a spoon. Grip the cover on the crosspiece and lift diagonally inwards. Remove cover completely.
- 6. Check impeller wheel and remove any foreign objects.
- 7. Place cover in the original position and press down until it engages (click).
- 8. Install filters.
- 9. Re-insert baskets.
- Risk of cuts!
- Fault table
- m Warning
- 4 Customer service
- 5 Installation and connection
- Installation and connection
- Product package
- Safety instructions
- Delivery
- Technical specifications
- Installation
- Waste-water connection
- Drinking water connection
- Warm water connection *Warm water connection
- Electrical connection
- Removing the appliance
- Transportation
- Drain the appliance according to the following steps:
- 1. Turn on the tap.
- 2. Open the door.
- 3. Switch on ON/OFF switch (.
- 4. Select programme with the highest temperature.
- 5. Press START button )".
- 6. Close the door.
- 7. Open door after approx. 4 minutes.
- 8. Press START button )" until ‹:‹‚ is indicated on the digital display.
- 9. Close the door.
- 10. Open door after approx. 1 minute.
- 11. Switch off ON/OFF switch (.
- 12. Turn off the tap, disconnect supply hose and drain water.
- Drain the appliance according to the following steps:
- Protection against frostProtection against frost (Emptying the appliance)
