Bryant CeilingPAC 502A - Manual (Page 2)

2
TABLE OF CONTENTS
Page
Features/Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Model Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . 2
ARI Capacity Ratings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Field-Installed Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Base Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9,10
Typical Wiring Schematics . . . . . . . . . . . . . . . . . . . . . . . . 10-13
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,16
MODEL NUMBER NOMENCLATURE
ARI* CAPACITY RATINGS
LEGEND
*Air-conditioning and Refrigeration Institute.
NOTES:
1. Ratings are at zero condenser air static and rated in accordance with ARI
Standard 210.
UNIT
502A
V-PH-Hz
TOTAL
kW
NET TOTAL
COOLING CAP. (Btuh)
NOMINAL
CFM
EER SEER
SEER
(with TDR)
SOUND RATING
(dB)
024 208/230-1-60 2.6 25,000 800 — 10.80 11.00 78
036
208/230-1-60
4.3 36,000 1200
— 10.00 10.05
82 208/230-3-60 9.0 — —
460-3-60 9.0 — —
048
208/230-1-60
5.5 49,500 1600
— 10.20 10.40
82
208/230-3-60 9.1 — —
460-3-60 9.1 — —
575-3-60 9.1 — —
060
208/230-1-60
6.9 58,500 2000
— 9.75 10.05
82
208/230-3-60 8.55 — —
460-3-60 8.55 — —
575-3-60 8.55 — —
dB — Decibels
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
TDR — Time-Delay Relay
2. EER =
NET CAPACITY (Btuh)
TOTAL WATTS
502A P X 048 000 AB
Model Designation
502A Horizontal, Indoor
Single-Package Cooling Unit
Voltage
J — 208/230-1-60
P — 208/230-3-60
E — 460-3-60
T — 575-3-60
Nominal Tons
024 — 2
036 — 3
048 — 4
060 — 5
X — Heat Not Installed
(field-installed electric heaters available)
Electric Heaters
000 — No factory-installed electric heaters
Indoor Fan Motor
AA — Standard Motor
AB — 1.5 hp Optional Motor*
*Factory-Installed option, contact your local representative for specific information.
