• PB8120 (SVGA) screen size chart
Connecting to Various Equipment
HDTV description
The projector is capable of displaying various High Definition TV display modes. Some of
these sources are:
Most of these sources will provide an analog component video output, a standard VGA
output, or a YP
b P r (default) format.
The projector is capable of accepting HDTV data through a YP b P r connector. Use a HDTV
cable that came with your projector to display HDTV images.
The following standards are supported in the HDTV function:
Please refer to Menu System on page 16 for information on the HDTV OSD selections.
Distance from
screen Diagonal measurement Distance from
screen Diagonal measurement
Minimum
zoom Maximum
zoom Minimum
zoom Maximum
zoom
feet inches feet inches feet inches meters cm meters cm meters cm
4 48 1.96 23.5 2.40 28.7 1 100 0.49 48.9 0.60 59.9
6 72 2.93 35.2 3.59 43.1 1.5 150 0.73 73.4 0.90 89.8
8 96 3.91 47.0 4.79 57.5 2 200 0.98 97.8 1.20 119.8
10 120 4.89 58.7 5.99 71.9 2.5 250 1.22 122.3 1.50 149.7
12 144 5.87 70.4 7.19 86.2 3 300 1.47 146.7 1.80 179.7
14 168 6.85 82.2 8.39 100.6 3.5 350 1.71 171.2 2.10 209.6
16 192 7.83 93.9 9.58 115.0 4 400 1.96 195.7 2.40 239.6
18 216 8.80 105.7 10.78 129.4 4.5 450 2.20 220.1 2.70 269.5
20 240 9.78 117.4 11.98 143.7 5 500 2.45 244.6 2.99 299.5
22 264 10.76 129.1 13.18 158.1 5.5 550 2.69 269.0 3.29 329.4
24 288 11.74 140.9 14.37 172.5 6 600 2.93 293.5 3.59 359.4
26 312 12.72 152.6 15.57 186.9 6.5 650 3.18 317.9 3.89 389.3
28 336 13.70 164.3 16.77 201.2 7 700 3.42 342.4 4.19 419.3
30 360 14.67 176.1 17.97 215.6 7.5 750 3.67 366.8 4.49 449.2
32 384 15.65 187.8 19.17 230.0 8 800 3.91 391.3 4.79 479.1
• Digital-VHS (D-VHS) player • DVD player
• Satellite Dish HDTV receiver • DTV tuners
• 480i • 480p
• 720p • 1080i
