Introduction
6
Projector Descriptions
Front View
Left View
Back View
Bottom View
Speaker
Ventilation grill
Projection lens
Projection lens
adjuster
External control
panel (see next
page)
Front adjuster
IR remote sensor
RGB signal output
S-Video jack
Audio/ Video connector
YP
b
P
r
connector
Audio jack
RGB signal input
USB mouse connector
RS 232 control port
Rear adjustment foot
Ventilation grill
IR remote sensor
Lamp door
