IMPORTANT NOTE: You must install the Card’s driver
(software) BEFORE connecting the hardware to your
computer.
1. Insert the included installation CD into your CD-
ROM drive. After a few moments, the main menu will
automatically start and display the following options.
NOTE: If main CD does not auto-start, click the “Start”
button and select “Run”. From the “Run” dialog box, enter
“:\Windows\setup.exe” and click “OK” (“”
being the letter of the drive that identifies your CD-ROM
driver under “My Computer”. For example, if the CD is in
drive D, enter “D:\Windows\Setup.exe”).
2. Select “Install Driver”. The software installation wizard will
appear and begin to download drivers.
3. After the files have been copied over successfully, shut
down your computer through the “Start” menu and begin
the “Hardware Installation” procedure outlined in the
following section.
Software Setup
