Do not connect the LAN cable to a power supply. It could cause
damage or malfunction.
DC IN 19V jack The AC adaptor connects to this socket to power
the computer. Please note that you should only
use the model of AC adaptor supplied with the
computer at the time of purchase - using the
wrong AC adaptor can cause damage to the
computer (depends on the model you
purchased).
Wireless Keyboard
Front
The following figure shows the front of the wireless keyboard.
Figure 2-5 Front of the wireless keyboard
Back
The following figure shows the back of the wireless keyboard.
Figure 2-6 Back of the wireless keyboard
1 5 2 3 4
1. Stand 4. Battery cover
2. Connect button 5. Stand
3. Power switch (keyboard)
Stand Used to let the keyboard tilted at an angle.
User's Manual 2-8
