Page 24
Figure B
Replacing the Oven Door
• The door can be replaced by reversing the above
procedure.
• After moving the hinge brackets back down into position,
be sure to close and open the door slowly to assure that
it is correctly and securely in place.
• Door should be straight, not crooked.
Maintenance
Replacing an Oven Light
• Your range has one light.
• Each light assembly consists of a removable lens, a light bulb as well as a light socket housing that is fixed in
place.
1. Read WARNING at right.
2. Turn off power at the main power supply (fuse or breaker
box).
3. Remove the lens by unscrewing it.
4. Remove the light bulb from its socket by unscrewing it.
5. Replace the bulb with a new one. Use a 40Watt approved
appliance bulb. Avoid touching the bulb with fingers, as
oils from hands can damage the bulb when it becomes
hot.
6. Screw the lens back on.
7. Turn power back on at the main power supply (fuse or
breaker box).
1. Be sure to read the above WARNING before attempting
to remove oven door.
2. Open the door completely.
3. Flip lever on hinge toward you. (see Figure A).
4. Close the door to approximately halfway open.
5. Holding the door firmly on both sides using both hands,
pull the door straight out of the hinge slots. Hold firmly,
the door is heavy (See Figure B).
6. Place the door in a convenient and stable location for
cleaning.
Removing the Door
• Make sure the oven and lights
are cool and power to the oven has
been turned off before replacing the
light bulb(s). Failure to do so could
result in electrical shock or burns.
• The lens must be in place when
using the oven.
• The lens serves to protect the
light bulb from breaking.
• The lens is made of glass.
Handle carefully to avoid breakage.
Broken glass could cause an injury.
WARNING
• Make sure oven is cool and power to the oven
has been turned off before removing the door.
Failure to do so could result in electrical shock or
burns.
• The oven door is heavy and fragile. Use both
hands to remove the oven door. The door front
is glass. Handle carefully to avoid breakage.
• Grasp only the sides of the oven door. Do not
grasp the handle as it may swing in your hand
and cause damage or injury.
• Failure to grasp the oven door firmly and
properly could result in personal injury or product
damage.
WARNING
Figure A
