BCS-HW919/HTZ-BD91HW/HTZ-HW919BD

Revisions to the Operating Instructions

Before revision

After revision

Accessories of speaker box

(S-BD919HW/S-BD91HW)

Non-skid pads (2)

Accessories of speaker box

(S-BD919HW/S-BD91HW)

Non-skid pads (6)

Speaker Setup

Preparing the speakers

1 Attach the non-skid pads to the base of each speaker.

For front speaker:
Use the supplied adhesive to attach two pads
to the base (bottom) of speaker.

Non-skid pads

Speaker Setup

Preparing the speakers

1 Attach the non-skid pads to the base of each speaker.

For front speaker:
Use the supplied adhesive to attach six pads
to the base (bottom) of speaker.

Non-skid pad
(for front)

Non-skid pad
(for front)

Affix to
three locations

Wall mounting the speaker

1 Use a Phillips screwdriver to remove the two screws

holding the stands to the speaker.

Wall mounting the speaker

1 Remove the base plates.

The base plates are held in position by the use of 2-sided
tape. While holding the leg in place, strongly press the
base plate in the direction indicated by the arrow to
remove the base plate. Be careful not to damage the
front speaker while doing this.

Base plate

Leg

2 Use a Phillips screwdriver to remove the two screws

holding the legs to the speaker.

Be sure to read these revisions before installing the product.
