Additional information 09
62
En
Chapter 9
Additional information
Screen sizes and disc formats
When viewing on a standard TV or monitor
Screen format of disc Setting Appearance
16:9 4:3 (Letter Box) The program is shown in
wi
d escreen with black bars at
the top an d bottom of the
screen.
4:3 (Pan & Scan) The si d es of the program are
croppe d so that the picture
fills the whole screen.
4:3 16:9 The program appears
squashe
d . Set to either 4:3
(Letter Box) or 4:3 (Pan &
Scan) .
4:3 (Letter Box)
4:3 (Pan & Scan) The program is presented
correctly on either setting.
When viewing on a widescreen TV or monitor
Screen format of disc Setting Appearance
16:9 16:9 The program is presente d in
wi d escreen.
4:3 16:9 Your TV will d etermine how the
picture is presente d —check
the manual that came with the
TV for
d etails.
