45
Electrical Requir ement
- Operating DC Voltage
14.4VDC (10.8-15.1V)
- Fuse
2A
RF Parameter
- 174Mhz to 230Mhz, 470Mhz to 862Mhz
Yes
- Antenna input connector
F Type
- 5V Antenna output from tuner
Yes
- Mini dip switch for Supplying for Antenna 5V Output
Yes
COFDM Modulation
- QPSK, 16QAM and 64QAM
Yes
- Transmission mode 2K & 8K FFT
Yes
- Guard Interval 1/4,1/8,1/16,1/32
Yes
- Code Rate 1/2, 2/3, 3/4, 5/6, 7/8
Yes
TV System
- DVB-T Compliance ETSI EN300 744
Yes
- Pal
Yes
- Aspect Ratio 4:3 and 16:9
Yes
- Video Encoding MPEG2 (ISO/IEC 13818-2, ML)
Yes
Video/Audio Par ameter
-Video Output Connector
1 x RCA
-Video Output level, 1Vpp 5%@75Ohms
Yes
-Audio Output Connector
1pair x RCA
-Audio Output level 1Vrms 20%@10KOhms
Yes
- Audio frequency range 20Hz to 20Khz
Yes
Common Inter face
- Single slot
Yes
Infra Red Extensions
- 5m of Infra-Red Remote Sensor
Yes
- e mark
Yes
Standar d Packaging Content
- Receiver
Yes
- Remote Controller
Yes
- Mounting Bracket (1pair)
Yes
- IR remote sensor extension cable
Yes
- Manual
Yes
9. SPECIFICATION
