Cautions on copyrights

rekordbox restricts playback and duplication of copyright-protected
music contents.
! When coded data, etc., for protecting the copyright is embedded in

the music contents, it may not be possible to operate the program
normally.

! When rekordbox detects that coded data, etc., for protecting the

Recordings you have made are for your personal enjoyment and accord-
ing to copyright laws may not be used without the consent of the copy-
right holder.
! Music recorded from CDs, etc., is protected by the copyright laws of

individual countries and by international treaties. It is the full respon-
sibility of the person who has recorded the music to ensure that it is
used legally.

! When handling music downloaded from the Internet, etc., it is the

full responsibility of the person who has downloaded the music to
ensure that it is used in accordance with the contract concluded
with the download site.

Specifications

AC adapter

Power ............................................................ AC 100 V to 240 V, 50 Hz/60 Hz
Rated current ......................................................................................... 0.6 A
Rated output ............................................................................... DC 12 V, 2 A
Power consumption (standby) ............................................................. 0.5 W

General – Main Unit

Power consumption ............................................................................... 1.3 A
Main unit weight ...................................................................................3.8 kg
Max. external dimensions .......623 mm (W) × 65 mm (H) × 289.5 mm (D)
Tolerable operating temperature ........................................ +5 °C to +35 °C
Tolerable operating humidity ...................... 5 % to 85 % (no condensation)

Wireless LAN section

Supported standards ................................IEEE 802.11b/g/n (2.4 GHz band)

Audio Section

Sampling rate .......................................................................44.1 kHz, 48 kHz
A/D, D/A converter ...............................................................................24 bits
Frequency characteristic

WLAN/USB/LINE ............................................................ 20 Hz to 20 kHz

S/N ratio (MASTER OUT 1, rated output, A-WEIGHTED)

WLAN/USB PLAY (when external input terminal not connected)
....................................................................................................... 105 dB
LINE ................................................................................................. 94 dB
PHONO............................................................................................ 84 dB
MIC .................................................................................................. 79 dB

Total harmonic distortion (MASTER OUT 1, 20 Hz — 20 kHzBW)

WLAN/USB PLAY ........................................................................0.003 %
LINE ..............................................................................................0.006 %

Standard input level / Input impedance

LINE .................................................................................. –12 dBu/47 kW
PHONO............................................................................. –52 dBu/47 kW
MIC ................................................................................... –52 dBu/12 kW

Standard output level / Load impedance / Output impedance

MASTER OUT 1 ........................................ +6 dBu/10 kW/1 kW or lower
MASTER OUT 2 ........................................ +2 dBu/10 kW/1 kW or lower
PHONES ..................................................................+3.8 dBu/32 W/51 W

Rated output level / Load impedance

MASTER OUT 1 ..............................................................+24 dBu/10 kW
MASTER OUT 2 ..............................................................+20 dBu/10 kW

Crosstalk (20 Hz — 20 kHzBW)

LINE ................................................................................................. 89 dB

Channel equalizer characteristic

HI .......................................................................... –∞ to + 9 dB (13 kHz)
MID ......................................................................... –∞ to + 9 dB (1 kHz)
LOW ........................................................................ –∞ to +9 dB (70 Hz)

Microphone equalizer characteristic

LOW — CENTER — HI .......–12 dB (10 kHz) to 0 dB to –12 dB (100 Hz)

Input/output terminals

USB downstream port

Type A ................................................................................................1 set
Power supply ..............................................................5 V/500 mA or less

USB upstream port

B type .................................................................................................1 set

MASTER OUT 1 output terminal

TRS phone jack (Ø 6.3 mm) ..............................................................1 set

MASTER OUT 2 output terminal

RCA pin jacks ....................................................................................1 set

PHONES output terminal

Stereo phone jack (Ø 6.3 mm) .........................................................1 set
Stereo mini phone jack (Ø 3.5 mm) .................................................1 set

PHONO/LINE input terminals

RCA pin jack .................................................................................... 2 sets

MIC input terminal

Phone jack (Ø 6.3 mm) .....................................................................1 set
— The specifications and design of this product are subject to

change without notice.

— The software screens used in these operating instructions are

from the development stage and may differ from the actual
screens.

! The articles concerning free repairs, etc., indicated in the warranty

do not apply to the rekordbox music management software. Carefully
read the articles in the software license agreement included in the
operating instructions before installing and using rekordbox.
