Pioneer XDJ-R1 - Manual (Page 34)

34 En
Names of switches and
indicators
MIDI message (computer to this unit)
Remarks (dd values) When SHIFT button
is off
When SHIFT button
is on
BEAT control
Deck A B4 0 dd B4 16 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck B B5 0 dd B5 16 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck C B4 8 dd B4 24 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck D B5 8 dd B5 24 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
FX SELECT button
(TRANS)
Deck A 94 70 dd 94 98 dd Off = 0, lit = 127
Deck B 95 70 dd 95 98 dd Off = 0, lit = 127
Deck C 94 74 dd 94 102 dd Off = 0, lit = 127
Deck D 95 74 dd 95 102 dd Off = 0, lit = 127
FX SELECT button
(FLANGER)
Deck A 94 71 dd 94 99 dd Off = 0, lit = 127
Deck B 95 71 dd 95 99 dd Off = 0, lit = 127
Deck C 94 75 dd 94 103 dd Off = 0, lit = 127
Deck D 95 75 dd 95 103 dd Off = 0, lit = 127
FX SELECT button
(ECHO)
Deck A 94 72 dd 94 100 dd Off = 0, lit = 127
Deck B 95 72 dd 95 100 dd Off = 0, lit = 127
Deck C 94 76 dd 94 104 dd Off = 0, lit = 127
Deck D 95 76 dd 95 104 dd Off = 0, lit = 127
FX SELECT button (ROLL)
Deck A 94 73 dd 94 101 dd Off = 0, lit = 127
Deck B 95 73 dd 95 101 dd Off = 0, lit = 127
Deck C 94 77 dd 94 105 dd Off = 0, lit = 127
Deck D 95 77 dd 95 105 dd Off = 0, lit = 127
TAP button
Deck A 94 88 dd 94 116 dd Off = 0, lit = 127
Deck B 95 88 dd 95 116 dd Off = 0, lit = 127
Deck C 94 89 dd 94 117 dd Off = 0, lit = 127
Deck D 95 89 dd 95 117 dd Off = 0, lit = 127
LEVEL/DEPTH control
Deck A B4 2 dd B4 18 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck B B5 2 dd B5 18 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck C B4 10 dd B4 26 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
Deck D B5 10 dd B5 26 dd
0-127
When turned fully counterclockwise: 0 / When turned fully clockwise:
127
SOUND COLOR FX
buttons
FILTER 94 78 dd 94 106 dd Off = 0, lit = 127
PITCH 94 79 dd 94 107 dd Off = 0, lit = 127
CRASH 94 80 dd 94 108 dd Off = 0, lit = 127
NOISE 94 81 dd 94 109 dd Off = 0, lit = 127
4 Others (when remotebox connected)
Names of switches and indicators (remotebox) MIDI message (this unit to computer) Remarks (dd values)
Deck switching
Deck C dA 90 90 dd OFF=0, ON=127
Deck D dB 91 90 dd OFF=0, ON=127
Deck A dC 92 90 dd OFF=0, ON=127
Deck B dD 93 90 dd OFF=0, ON=127
Needle search pad Bn 105 dd
0-127
0 at left edge, 127 at right edge
