32 En
Names of switches and indicators
MIDI message (computer to this unit)
Remarks (dd values) When SHIFT button
is off
When SHIFT button
is on
EQ [HI] control
Deck A B6 7 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck B B6 8 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck C B6 9 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck D B6 10 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
EQ [MID] control
Deck A B6 11 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck B B6 12 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck C B6 13 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck D B6 14 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
EQ [LOW] control
Deck A B6 15 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck B B6 16 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck C B6 17 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck D B6 18 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
COLOR control
Deck A B6 27 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck B B6 28 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck C B6 29 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Deck D B6 30 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
HEADPHONES CUE button
Deck A 96 84 dd 96 96 dd Off = 0, lit = 127
Deck B 96 85 dd 96 97 dd Off = 0, lit = 127
Deck C 96 86 dd 96 98 dd Off = 0, lit = 127
Deck D 96 87 dd 96 99 dd Off = 0, lit = 127
HEAD PHONES MIXING control B6 1 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
HEAD PHONES LEVEL control B6 2 dd — — —
0-127
When turned fully counterclockwise: 0 / When turned fully
clockwise: 127
Channel fader
Deck A B6 19 dd — — —
0-127
Lower edge: 0 / Upper edge: 127
Deck B B6 21 dd — — —
0-127
Lower edge: 0 / Upper edge: 127
Deck C B6 23 dd — — —
0-127
Lower edge: 0 / Upper edge: 127
Deck D B6 25 dd — — —
0-127
Lower edge: 0 / Upper edge: 127
Crossfader B6 31 dd — — —
0-127
Left edge: 0 / Right edge: 127
MIC (ON/OFF)button 96 70 dd 96 102 dd Off = 0, lit = 127
AUX (ON/OFF) button 96 75 dd 96 103 dd Off = 0, lit = 127
