Front panel
1  STANDBY/ON (page 18)
2 Disc tray
3  OPEN/CLOSE (page 20)
4 Display
5 TOP MENU (page 22)
6 ENTER & cursor buttons (page 18)
7 MENU (page 22)
8 RETURN (page 22)
9 HOME MENU (page 18)
10 USB port (Type A) (page 32)
11 DVD/USB (page 32)
12  (page 21)
13  (page 21)
14  (page 21)
15  and  (page 21)
16 HDMI indicator
Lights when this player is recognized by
another HDMl or DVI/HDCP compatible
component.
OPEN/CLOSE HDMI
HOME
MENU RETURN
ENTER
TOP MENU MENU
USB DVD/USB
STANDBY/ON
2 5 3 4 6 7 1
9 8 10 12 11 16 13 14 15
