10
Application Operations (Continued)
2 Date and time
Display the date and time when the measurement data was transferred to the PC.
3 Channel and frequency switch buttons
Ch: Selects channel display mode (frequencies are displayed along graph depth axes).
Freq: Selects frequency display mode (channels are displayed along graph depth axes).
4 All/individual display switch menu
Allows you to select All display or individual display (Front L, etc.).
5 Level [dB]
The level axis.
6 Time [msec]
The time axis.
7 Channel memo (available only when individual channels are shown)
Allows you to record a short memo about each channel.
8 Graph adjustment bar
Z: Increases or reduces the display unit of the Level [dB] scale.
M: Moves the Level [dB] scale.
E: Moves the viewpoint of 3D graphs vertically. (Cannot be changed for 2D graphs.)
R: Moves the viewpoint of 3D graphs horizontally. (Cannot be changed for 2D graphs.)
