11
En
English
Dimensions Diagram
50 inch display model (under speaker models)
Unit: mm (inch)
380 (14-31/32)
161
(6-11/32)
126
(4-31/32)
27 (1-1/16)
93 (3-21/32)
80 (3-5/32)
803 (31-5/8)
1233 (48-17/32)
577 (22-23/32)
866 (34-3/32)
291.5
(11-15/32)
50 inch display model (except under speaker models)
Unit: mm (inch)
380 (14-31/32)
27 (1-1/16)
93 (3-21/32)
577 (22-23/32)
211
(8-5/16)
161
(6-11/32)
80 (3-5/32) 723 (28-15/32)
1233 (48-17/32)
786 (30-15/16)
126
(4-31/32)
