Assembling the Stand
Assembly Procedure
1. Align the long holes in the tooling and in the column and lay them on their side.
2. Attach the stand by aligning the screw hole on the bottom of the column with the
protrusion on the base.
z Be careful that you do not strike the glass.
3. Tighten the screws on the back surface of the base with a hexagonal wrench
(three locations).
z Firmly tighten all three locations.
Tooling
Column
Base
