The navigation unit

Blue/white (*6)

Blue/white (*7)
Connect to auto-aerial relay control terminal
(max. 300 mA 12 V DC).

The pin position of the ISO connector will
differ depends on the type of vehicle.
Connect *6 and *7 when Pin 5 is an
antenna control type. In another type of
vehicle, never connect *6 and *7.

Fuse (10 A)

Power cord

Note

The aerial will automatically retract, yet the timing varies depending on
the setting.
