23 En
English
Changing the settings
1 Press the [MIDI] [SETUP (WAKE UP)] button for at
least 1 second.
The [USER SETUP] screen is displayed.
! To display the [CLUB SETUP] screen, first turn the unit’s power off,
then press the [POWER] button while pressing the [MIDI] [SETUP
(WAKE UP)] button.
2 Press the [BEAT c, d] button.
Select the setting item.
3 Press the [TAP] button.
The screen switches to the setting item’s setting value change screen.
4 Press the [BEAT c, d] button.
Change the setting value.
5 Press the [TAP] button.
Enter the setting value.
The previous screen reappears.
! To return to the previous screen without changing the settings, press
the [AUTO/TAP] button.
6 Press the [SETUP (WAKE UP)] button.
Close the [USER SETUP] screen.
! To close the [CLUB SETUP] screen, press the [POWER] button to turn
this unit’s power off.
About the auto standby function
When [Auto Standby] is set to [ON], the standby mode is set automati-
cally if 4 hours pass with all of the conditions shown below met.
— That none of this unit’s buttons or controls are operated.
— That no audio signals of –10 dB or greater are input to this unit’s
input terminals.
! When the [SETUP (WAKE UP)] button is pressed, the standby mode
is canceled.
! This unit is shipped with the auto standby function turned on. If you
do not want to use the auto standby function, set [Auto Standby] to
[OFF].
About the talk over function
The talk over function has the two modes described below.
— [ADV] (advanced talk over): The mid-range only of the sound of chan-
nels other than the [MIC] channel is attenuated according to the
[Talk Over LEVEL] setting value and output.
dB
Frequency
— [NOR] (normal talk over): The sound of channels other than the [MIC]
channel is attenuated according to the [Talk Over LEVEL] setting
value and output.
dB
Frequency
Setting preferences
*: Setting upon purchase
Mode
Options
settings
Screen display Setting value Descriptions
USER SETUP
Fader Start F.S. ON*, OFF
Turns the fader start function on and off for all DJ players connected to the [CONTROL]
terminals.
MIDI CH MIDI CH 1* to 16 Sets the MIDI channel.
MIDI Button Type MIDI BT TGL*, TRG Selects the MIDI signal transmission mode, [TGL (TOGGLE)] or [TRG (TRIGGER)].
Talk Over Mode TLK MOD ADV*, NOR Selects the talk over function’s mode, [ADV(ADVANCED)] or [NOR(NORMAL)].
Talk Over LEVEL TLK LVL
–6 dB, –12 dB,
–18 dB*, –24 dB
Sets the talk over function’s sound attenuation level.
CLUB SETUP
Digital Master
Out Level
DOUT LV
–19 dB*, –15 dB,
–10 dB, –5 dB
Sets the maximum level of the sound output from the [DIGITAL MASTER OUT] terminals. 1
Digital Master
Out Sampling
Rate
DOUT FS 48 kHz, 96 kHz* Sets the digital signal’s sampling rate.
MASTER ATT. MST ATT
–6 dB, –3 dB,
0 dB* Sets the attenuation level of the sound output from the [MASTER1] and [MASTER2]
terminals.
Auto Standby AUTOSTB ON*, OFF Turns the auto standby function on and off.
Mic Output To
Booth Monitor
MIC BTH ON*, OFF Sets whether or not to output the microphone’s audio signals from [BOOTH] terminals.
PC UTILITY PC UTLY ON*, OFF
Sets whether or not to launch the computer’s setting utility software automatically
when a USB cable is connected.
Factory Reset INITIAL YES, NO* Restores all the settings to their factory defaults.
1 Note that the output sound may be distorted even if the master level indicator does not light up to the very top.
