Controls and displays 04
23
En
English 8 Receiver setting buttons
Set the remote control operation selector
switch to
RECEIVER first to access:
AUDIO PARAMETER – Use to access the
Audio options.
VIDEO PARAMETER – Use to access the
Video options.
HOME MENU – Use to access the Home
Menu.
RETURN – Press to confirm and exit the
current menu screen.
9 ////ENTER
Use the arrow buttons when setting up your
surround sound system and the Audio or Video
options.
10 Receiver Control buttons
Set the remote control operation selector
switch to
RECEIVER first to access:
STATUS – Press to check selected receiver
settings.
PHASE CTRL – Press to switch on/off
Phase Control or Full Band Phase Control.
CH LEVEL – Press repeatedly to select a
channel, then use
/ to adjust the level.
THX – Press to select a Home THX
listening mode.
PQLS – Press to select the PQLS setting.
AUTO/ALC/DIRECT – Switches between
Auto Surround, Auto Level Control,
Optimum Surround mode and Stream
Direct mode.
STEREO – Switches between stereo
playback and Front Stage Surround
Advance modes.
STANDARD – Press for Standard decoding
and to switch various modes (
2 Pro Logic,
Neo:6, etc.).
ADV SURR – Use to switch between the
various surround modes.
SIGNAL SEL – Use to select an input
signal.
SLEEP – Use to put the receiver in sleep
mode and select the amount of time
before sleep.
DIMMER – Dims or brightens the display.
A.ATT – Attenuates (lowers) the level of an
analog input signal to prevent distortion.
SBch – The SBch button can only be used
on models to which it applies.
MCACC – Press to switch between MCACC
presets.
HDMI OUT – Switch the HDMI output
terminal.
11 LIGHT
Press to turn on/off the illumination for the
buttons. 1
12 Remote control operation selector switch
Set to
RECEIVER to operate the receiver, TV or
SOURCE to operate the TV or the source
device.
When this switch is set to RECEIVER, the
receiver can be controlled (used to select the
white commands). Also use this switch to set
up surround sound.
13 VOL +/–
Use to set the listening volume.
14 MUTE
Mutes the sound or restores the sound if it has
been muted (adjusting the volume also
restores the sound).
Note
1 Press and hold in the LIGHT button for 5 seconds to change the illumination mode 1 or 2. When set to LIGHT MODE
2 (default), the illumination only lights when the remote control LIGHT button is pressed. When switched to LIGHT
MODE 1, the illumination lights whenever buttons are operated. Setting LIGHT MODE 1 will shorten the service life
of the batteries.
