Page 8: When connecting with a multi-channel processor

7
Connecting the Units
If AV system display (e.g. AVX-7600) is combined with
this unit, connect the rear view camera to the AV system
display. For details concerning connection methods, refer
to AV system display’s instruction manual.
If AV system display is not combined with this unit,
connect the rear view camera to this unit’s video input.
For details concerning connection, refer to page 10.
Blue
Black
Blue
Black
6 m
RCA cable
(supplied with multi-channel processor)
IP-BUS cable
(supplied with
multi-CD player)
Multi-CD player
(sold separately)
IP-BUS cable
(supplied with multi-channel processor)
Multi-channel processor
(DEQ-P6600)
(sold separately)
When connecting with a multi-channel processor
