52
MAINTENANCE
Periodically blow out all air passages with dry compressed air. All plastic parts should be cleaned
with a soft damp cloth. NEVER use solvents to clean plastic parts. They could possibly dissolve or
otherwise damage the material.
SPECIFICATIONS
VOLTAGE
AR 220V ~ 50Hz
B2C 220V ~ 50-60Hz
B3 120V ~ 60Hz
B2 220V ~ 60Hz
BR 127V~ 60Hz
POWER 1500W
NO-LOAD SPEED 0-5000 rpm
FAILURE TO START
Should your machine fail to start, check to make sure the prongs on the cord plug are making good
contact in the outlet. Also, check for blown fuses or open circuit breakers in the line.
Black & Decker offers a full network of company-owned and authorized service locations. All Black & Decker Service Centers are staffed with trained personnel to provide customers with efficient and
reliable power tool service. Whether you need technical advice, repair, or genuine factory replacement parts, contact the Black & Decker location nearest you, or visit us at www.BlackandDecker-la.com
pushblock from a jointer, 1 sheet of medium Scotch-Brite™ Blending Hand Pad, 1 can of WD-40®,
1 can of degreaser, 1 can of TopCote® Aerosol. Apply the WD-40 and polish the table surface
with the Scotch-Brite pad using the pushblock as a holddown. Degrease the table, then apply the
TopCote® accordingly.
PROTECTING CAST IRON FROM RUST
To clean and protect cast iron tables from rust, you will need the following materials: 1
LUBRICATION
Apply household floor paste wax to the machine table and tension table or other work surface weekly.
Wear ANSI Z87.1 safety glasses while using compressed air.
TROUBLESHOOTING
SERVICE INFORMATION
BE SURE TO FOLLOW SAFETY RULES AND INSTRUCTIONS
WHAT’S WRONG?
1. 1. Saw not plugged in.
2. Fuse blown or circuit breaker tripped.
3. Cord damaged.
4. Brushes worn out.
WHAT TO DO…
1. Plug in saw.
2. Replace fuse or reset circuit breaker.
3. Have cord replaced by authorized service center.
4. Have brushes replaced by authorized service center.
WHAT’S WRONG?
1. Dull blade.
2. Blade mounted backwards.
3. Gum or pitch on blade.
4. Incorrect blade for work being done.
WHAT TO DO…
1. Replace blade.
2. Turn blade around
3. Remove blade and clean with turpentine.
4. Change the blade
TROUBLE: SAW WILL NOT START
TROUBLE: SAW MAKES UNSATISFACTORY CUTS
WHAT’S WRONG?
1. Extension cord too light or too long.
2. Low house current.
WHAT TO DO…
1. Replace with adequate size cord.
2. Contact your electric company.
WHAT’S WRONG?
1. Stand or bench on uneven floor.
2. Damaged saw blade.
WHAT TO DO…
1. Reposition on flat level surface.
2. Replace blade.
TROUBLE: SAW DOES NOT COME UP TO SPEED
TROUBLE: MACHINE VIBRATES EXCESSIVELY
