Page 17
LIMIT THERMOSTAT
Location:
The limit thermostat is located inside the rear of
the hood on the center rear of the tank lid.
Test Procedures:
1. Disconnect the brewer from the power source.
2. Disconnect the blue and black wires from the limit
thermostat.
3. With an ohmmeter, check for continuity across the
limit thermostat terminals.
If continuity is present as described, the limit thermo-
stat is operating properly.
If continuity is not present as described, replace the
limit thermostat.
FIG. 5 LIMIT THERMOSTAT
