Olympus E-P3 - Manual (Page 2)

Memory SD Memory Card (SDHC, SDXC, UHS-I compatible), Eye-Fi, Class 6 is recommended for Movie shooting
Effective Pixels number Effective Pixels number 12.3 million pixels
Image Pickup Unit Product type High speed Live MOS Sensor
Total no. of pixels Approx. 13.1 million pixels
Aspect ratio 1.33 (4:3)
Dust reduction Supersonic Wave Filter (dust reduction system for image sensor)
Recording (Still) Recording format DCF, DPOF compatible/Exif, PRINT Image Matching III
File format RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO (3D still)
Recording image size [RAW] 4032 x 3024 pixels [JPEG] 4032 x 3024 pixels - 640 x 480 pixels
Recording (Movie) Recording format AVCHD AVI Motion JPEG
Recording (Sound) Recording format AVCHD Format : Dolby Digital Motion-JPEG Format / Picture with Sound : Wave Format Base (Stereo PCM/16bit, 48kHz)
Mic/Speaker Stereo/Mono
Image stabilizer System Built in (Imager shift image stabilizer)
Mode 3 modes (IS1:2 dimensional activation, IS2:1 dimensional activation in landscape frame to vertical direction moving,
IS3:1dimensional activation in portrait frame to vertical direction moving), OFF
IS for Movie Shifting electronic image (so called Digital IS, IS1 mode only)
Monitor Product type OLED, AF (Anti-Fingerprint) coating, Touch Panel
Size 3.0 inches 3:2
Total no. of pixels Approx. 614,000 dots
Playback field of view 100%
Focusing AF system Imager Contrast Detection AF system When non High-speed imager AF compatible lens is used, it works as AF assist.
Focus mode Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR)
C-AF and AF tracking are not available with non-mFTs lenses. This can be set in both recording mode, still and movie, separately.
Focusing point 35-area multiple AF with the contrast detection system (Auto, Selectable)
AF illuminator Available
AF lock Locked at first position of Shutter button in Single AF mode
Focus tracking Available
Maginified Spot AF Available
Face priority AF/Eye Detect AF Available Eye Detect AF : OFF / Near side eye priority mode / Right side eye priority mode / Left side eye priority mode
Manual Focus Assist When rotation of focus ring is detected under S-AF+MF or MF mode, Live View is magnified automatically
Exposure Control Metering system TTL Image Sensor metering system
(Still) (1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering (approx. 1% for the viewfinder screen. Highlight / shadow bases are available)
Metering range EV 0 - 20 (Digital ESP metering, Center weighted average metering, Spot metering) (At normal temperature, 17mm f2.8, ISO 100)
Exposure mode (1) i Auto (2) P: Program AE (Program shift can be performed) (3) A: Aperture priority AE (4) S: Shutter priority AE (5) M: Manual (6) Scene select AE (7) Art Filter
ISO sensitivity AUTO: ISO 200 - 12800 (customizable, Default 200-1600) / Manual ISO 200 - 12800, 1/3 or 1 EV steps,
Exposure compensation ±3 EV in 1/3, 1/2, 1 EV steps selectable
Exposure Control (Movie) Exposure mode (1) P: Program AE (2) A: Aperture priority AE (3) S: Shutter speed priority AE (4) M:Manual (5) Art Filter * S mode and M mode : Shutter speed is limited to 1/30 sec.
White Balance Auto WB system High speed Live MOS sensor
Preset white balance 6 settings (3000K - 7500K) Lamp (3000K), Fluorescent (4000K), Daylight (5300K), Flash (5500K), Cloudy (6000K), Shade (7500K)
Picture Mode Mode iEnhance, Vivid, Natural, Portrait, Muted, Monotone, Art Filter
Art Filter bracketing Available
Noise Filter at High ISO setting OFF, LOW, STANDARD, HIGH
Noise Reduction at Slow shutter speed OFF, ON, AUTO
Shutter Product type Computerized focal-plane shutter
Shutter speed 60 - 1/4000 sec. Bulb: up to 30 min. (selectable longest time in the menu. Default: 8 min) 1/3, 1/2, or 1EV steps selectable.
Remote cable release Available (Optional RM-UC1)
Flash Built-in flash Available
G.No 10 (Fno/m) at ISO200, 7(Fno/m) at ISO100 but ISO100 is not available
Wireless Flash Control Available (4ch, 3Groups+Built-in Flash) Built-in flash is usable as a center flash in case of wireless flash control.
Compatible external flash E-System Flash (FL-50R, FL-36R, FL-50, FL-36, FL-20, FL-14, FL-300R)
Art Filter Mode Pop Art, Soft Focus, Pale & Light Color, Light Tone, Grainy Film, Pin Hole, Diorama, Gentle Sepia, Cross Process, Dramatic Tone
Multi Exposure Number of picture 2 frames
Multi Aspect Aspect Ratio 4:3(Default) / 3:2 / 16:9 / 6:6 / 3:4
Level Gauge Detection Available (H & V)
Super control panel Available
Live Control Available
Live Guide Setting Menu Color saturation, Color image, Brightness, Blur Background, Express Motion, Shooting Tips
Image Editing Erasing function Single frame, All, Selected frames (from Index)
Protect function Single frame, Selected frames, All frames, Release protect (Single/All)
RAW picture editing RAW development based on settings of the camera (including Art Filter)
JPEG editing Shadow adjustment, Red-eye fix, Cripping, Aspect. Monotone, Sepia, Saturation (color depth), Resize (producing another file, 1280x960, 640x480, 320x240), e-portrait
Input/Output PC interface USB 2.0 High Speed for storage through Multi-connector (MTP mode is available)
TV interface HDMI (HD/Mono or Stereo Sound), VIDEO-OUT (SD/Mono Sound)
USB/Video connector Dedicated multi-connector (Video: NTSC/PAL selectable, Optional Remote cable RM-UC1, USB cable is available)
HDMI Mini HDMI type-C (1080i/720p/576p/480p)
Accessory attachment Accessory port (AP2) works with VF-2, SEMA-1, Macro Arm Light MAL-1 and Bluetooth communication Unit Olympus PENPAL
Power Requirements Battery BLS-1 Li-ion battery (included)
Dimensions/Weight Dimensions 4.80 in. (W) x 2.72 in. (H) x 1.35 in. (D) (excluding protrusions)
Weight 11.32 oz. (body only)
*Specifications are subject to change without notice.
Available Colors
Black
V204031BU000 with
Black 14-42mm IIR Lens
V204033BU000 with
Black 17mm Lens
Silver
V204031SU000 with
Silver 14-42mm IIR Lens
V204033SU000 with
Silver 17mm Lens
White
V204031WU000 with
Silver 14-42mm IIR Lens
V204033WU000 with
Silver 17mm Lens
Additional Technology
900907 *Specifications are subject to change without notice.
E-P3
NEW!
E-P3_Sale_Sheet 6/28/11 4:09 PM Page 2
