Camera diagram, Ap pend ix – Olympus Stylus 850 SW User Manual
Page 77
EN
77
Ap
pend
ix
CAMERA DIAGRAM
Camera
Flash (P. 18)
Shutter Button
(P. 9, 11)
LED Illuminator/
Self-Timer Lamp
(P. 18, 20, 40)
Lens (P. 62)
Zoom Button (P. 16)
f/S Button
(Shadow Adjustment
Technology/Erase)
(P. 10, 19)
Arrow Pad (
1243)
(P. 15)
o Button (OK/FUNC)
(P. 15)
Strap Eyelet
(P. 3)
Battery/Card Compartment
Cover (P. 4)
Tripod Socket
Connector Cover
(P. 40, 41, 47)
Multi-Connector
(P. 40, 41, 47)
Monitor (P. 38, 78)
m Button
(P. 16)
Microphone (P. 30)
Speaker
o Button
(P. 6, 11)
Card Access Lamp
(P. 49, 64)
Mode Dial
(P. 6, 10, 12)
q/< button
(Playback/Print) (P. 18)
g/E/Y Button
(P. 20)
d4361_e_0000_7.book Page 77 Monday, November 5, 2007 3:34 PM
