Olympus Stylus 720 SW - Manual (Page 2)

Imager: 7.1 Megapixel (effective), 7.4 megapixel gross,
1/2.33” CCD
Lens: 6.7 – 20.1mm (38 – 114mm equivalent in 35mm photography),
10 lenses in 8 groups, 3 aspherical lenses
Zoom: 3x Optical + 5x Digital; 15 Total Seamless Zoom
Aperture Range: f3.5 – f5.0
LCD: 2.5” (6.4cm) Color LCD, approx. 115,000 pixels
Focus System: CCD Contrast Detection
Focus Range: Normal mode: 19.7” – infinity (0.5m – infinity)
Macro mode: Wide: 7.9” – infinity (0.2m – infinity),
Super Macro Mode: 2.8” – 19.7” (7cm – 50cm)
Focus Mode: iESP Auto, Spot AF
Shutter Speed: 1/1000 sec. – 1/2 sec. (up to 4 sec. in Night Scene Mode)
ISO: Auto, 64, 100, 200, 400, 800, 1600 (equivalent)
Metering Mode: Digital ESP Multi-Pattern, Spot Metering
White Balance: Auto, Pre-set (Daylight, Overcast, Tungsten, and
Fluorescent1, Fluorescent2, Fluorescent3)
Exposure Compensation: ±2 EV steps in 1/3 EV steps
Recording Modes: Still Image: JPEG
Movie: QuickTime motion JPEG
Adjustment Resolutions: 3,072 x 2,304, SHQ/HQ
2,560 x 1,920, SQ1
2,304 x 1,728, SQ1
2,048 x 1,536, SQ1
1,600 x 1,200, SQ2
1,280 x 960, SQ2
1,024 x 768, SQ2
640 x 480, SQ2
Shooting Modes: 28 Shooting Modes; Auto, Program Auto, Digital Image
Stabilization Mode, Scene Preset (Portrait, Landscape,
Landscape & Portrait, Night Scene, Night & Portrait, Sport,
Indoor, Candle, Self-Portrait, Available Light Portrait, Sunset,
Fireworks, Museum, Cuisine, Behind Glass, Documents,
Auction, Shoot & Select1, Shoot & Select2, Beach & Snow,
Under Water Wide1, Under Water Wide2, Under Water
Macro, Under Water Snapshot, Movie)
Panorama: Up to 10 frames automatically stitchable with OLYMPUS
Master software when using Olympus brand xD-Picture Card™
Sequential shooting: High speed: 3.7 frames per second up to 11 frames in HQ mode
Normal speed: 1.1 frames per second up to 6 frames in SQ mode
Shooting Assist Functions: Histogram, Frame Assist
Movie Mode: QuickTime ® Movie with Sound: 640x480/15fps, SHQ;
320x240/15 fps, HQ; 160x120/15fps, SQ
Image Processing: TruePic TURBO™ Image Processor
Pixel Mapping: Automatic Pixel Mapping (APM) available via menu setting
Noise Reduction: Set automatically at shutter speeds of 0.5 second or longer
Image Playback: Still Image: Single, Index display (4/9/16/25), Up to 10x
enlargement, Slideshow, Rotation, Calendar, Album,
Histogram
Movie: Normal, Reverse, Frame-by-frame
Playback Edit Effects: Still Image: Black & White, Sepia, Resize, Rotation, Red-Eye
Fix, Brightness, Saturation, Frame, Label, Calendar
Movie: Frame Index
Direct Printing Options: PictBridge and DPOF
Flash: Built-in
Flash Modes: Auto (for low light and back lit conditions), Red-Eye
Reduction, Fill-In, Off
Flash Working Range: Wide: 12.5ft (3.8m), Tele: 8.5ft (2.6m)
Self-Timer: 12 Seconds/Auto
Settings Memorization: On/Off (Hold changes/Reset to default settings)
Date/Time Calendar: Simultaneous recording into image data, Automatic
up to 2099
Memory: 19.1MB internal memory
Removable Media Card: xD-Picture Card™ (16, 32, 64, 128, 256, 512MB or 1GB)
Outer Connectors: Multi-terminal (USB connecter, Audio/Video output,
DC input*)
*Optional connector is required.
Auto-Connect USB: 2.0 Full Speed (USB mass storage)
Resistance Properties: Shock Proof (5 ft.), Waterproof (10 ft.), Dust Proof
System Requirements: Auto-connect USB: Windows 98SE/ME/2000PRO/XP with
USB port, Mac OS 9.0-9.2x/OS X 10.1-10.4 with USB port
Software: Windows 98SE/ME/2000PRO/ XP, Mac 10.2 and
higher
Operating Environment: Operation: 32° – 104°F (0° – 40°C), 30% – 90% humidity
Storage: -4° – 140°F (-20° – 60°C), 10% – 90% humidity
Power Supply: Li-Ion Rechargeable Battery (Li-40B or Li-42B), AC Adapter
(E-7AC) with optional CB-MA1 DC coupler
Size: 3.6” W x 2.3” H x 0.78” D (91mm x 58.7mm x 19.8mm)
Weight: 5.3 oz. (149g) without battery and media card
Olympus ® Stylus ® 720 SW Specifications Stock No. 225765
Specifications subject to change without notice or obligation on the part of the manufacturer.
© 2006 Olympus Imaging America Inc. All rights reserved. Printed in the United States of America. Olympus and
Stylus are trademarks or registered trademarks of Olympus Corporation, Olympus Imaging America Inc. or their
affiliated entities. All trademarks and registered trademarks listed herein are the property of their respective holders.
D1321-0206
Available Accessories
Package Contents
Stylus 720 SW Digital Camera
Li-42B Li-ion Rechargeable Battery and
Charger
USB Cable, Audio/Video Cable
Wrist Strap
Quick Start Guide
Basic Manual
2 CD-ROM’s (OLYMPUS Master Software
and Advanced Manual)
Warranty Card
olympusamerica.com
PT-033
Underwater Housing
202024
Stylus ® 720 SW
xD-Picture Card TM
128MB (200843)
256MB (202025)
512MB (200395)
1GB (200495)
Leather Case
(Vertical,
Top-Loading)
200398
LI-40B
Lithium Ion Battery
200345
Li-42B
Lithium Ion Battery
202034
Olympus Digital Still Cameras can be used with confidence wherever you go. They are backed by a one-
year repair warranty service that is available worldwide. Please contact our service center or check the
Authorized Distributors list for service and applicable areas of service. May not be available in all areas.
200400 Leather Case (Horizontal, Side-Loading)
200496 Metal Neck Strap
200830 MAUSB-10 xD-Picture Card™/
SmartMedia™ USB Reader/Writer
200335 MAUSB-300 xD-Picture Card™ USB
Reader/Writer
200837 MACF-10 xD-Picture Card™/Compact
Flash Adapter
200835 MAPC-10 xD-Picture
Card/SmartMedia™ PCMCIA/PC
Card Adapter
200987 POL-032 Oring for PT-033
200845 xD-Picture Card™ Media Wallet
200346 Li-40C Replacement Charger
200850 D-7AC AC Adapter
202053 CB-MA1 DC Coupler
(For Use With D-7AC)
200372 CB-USB6 Digital Camera USB Cable
(Replacement)
200347 CB-AVC3 Digital Camera A/V Cable
(Replacement)
202044 2-Year Extended Digital Warranty
202057 Stylus Digital Accessory Kit
Includes Case, Battery and Metal
Neck Strap
