AEG S84000KMX0 - Manual (Page 19)

2. Remove the bottom hinge (A) by un-
screwing the fixing screws.
3. Remove the door.
4. Unscrew the pin (f) of the bottom hinge
and install it on the opposite side.
5. Unscrew the pin of the upper hinge and
install it on the opposite side.
6. Install the door in the upper hinge.
7. Install the ventilation grille, clipping it
into place.
8. Remove the handle. Unscrew the top
handle bracket from the handle rod (h1).
Unscrew the bottom handle bracket
from the door (h2). Unscrew the top
handle bracket from the door (h3).
9. Install the handle in the opposite side.
Re-screw the handle bracket on the
door (h4). Turn the handle bracket with
the handle and screw them to the door
(h5) and the fitted handle bracket
10. Make sure that the front board of the
door is parallel to the front board of the
top.
11. Reposition, level the appliance, wait for at least four hours and then connect it to the
power socket.
Do a final check to make sure that:
• All screws are tightened.
• The magnetic seal adheres to the cabinet.
• The door opens and closes correctly.
If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the
cabinet. In that case, wait for the natural fitting of the gasket.
A
e
f
A
h1 h2 h3
h4 h5 h6
Installation 19
