AEG S84000KMX0 - Manual (Page 16)

TECHNICAL DATA
Dimension of the recess
Height 1800 mm
Width 600 mm
Depth 650 mm
Voltage 230-240 V
Frequency 50 Hz
The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.
INSTALLATION
WARNING!
Read the "Safety Information" carefully for your safety and correct operation of the appli-
ance before installing the appliance.
Location
The appliance should be installed well away from
sources of heat such as radiators, boilers, direct
sunlight etc. Ensure that air can circulate freely
around the back of the cabinet. To ensure best
performance, if the appliance is positioned below
an overhanging wall unit, the minimum distance
between the top of the cabinet and the wall unit
must be at least 100 mm . Ideally, however, the
appliance should not be positioned below over-
hanging wall units. Accurate levelling is ensured
by one or more adjustable feet at the base of the
cabinet.
If the cabinet is placed in a corner and the side
with the hinges facing the wall, the distance be-
tween the wall and the cabinet must be at least 10 mm to allow the door to open enough
so that the shelves can be removed.
WARNING!
It must be possible to disconnect the appliance from the mains power supply; the plug
must therefore be easily accessible after installation.
10mm 10mm
100mm
16 Technical data
