Step 7

Attach the door bracket to the front
legs of the cart frame assembly
using four 1/4” X 1/2” bolts.

Note: When performing Step 8,

Lift grill body from front
and rear panels to avoid
injury to hands and
fingers.

Step 8

With the help of a friend, place grill
body assembly on grill cart. Grill
body will rest between upper side
sections of cart. Align front edge of
grill body assembly with front edges
of cart frame legs. Secure using
four 1/4” X 1/2” bolts and four star
washers. At this point, fully tighten
six bolts holding back panel from
Step 4 and four bolts holding door
bracket.
