ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
21
1 Rear Cart Panel
1 Door Frame
1 Grease Tray
1 Grease Cup
1 Left Side Cart Panel
2 Doors
1 Right Side Cart Panel
1 Hose Heat Shield
2 Locking Casters
1 Left Door Bracket
1 Right Door Bracket
1 Bottom Cart Shelf
2 Rubber Wheels
2 Wheel Covers
PARTS LIST:
1 Hood
1 Left Side Table
1 Right Side Table
1 Left Side Table Front Panel
1 Right Side Table Front Panel
1 Left Side Table Handle
5 Left Side Table Hooks
1 Electronic Igniter Button
1 Electronic Igniter Spring
1 Side Burner Bezel
1 Side Burner Knob
1 Side Burner Grate
1 Warming Rack
2 Cooking Grills
4 Heat Distribution Plates
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
22
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this ProSeries 6430 Grill:
• Flathead Screwdriver (included)
• Hex Nut Wrench (included)
20
23
24
25
26
27
29
28
