INSTRUCTION LABELS
CONTROLS
These labels should be included on your Vacuum. If any of these
labels are damaged, replace them before putting this equipment into
operation. Item and part numbers are given to help in ordering
replacement labels..
Label Danger Keep Hands
and Feet Away
Item 3 Part No.400424
Label Do Not Fill While Engine Is Hot
Item 81 Part No.400268
EXPLOSIVE FUEL
STOP ENGINE AND ALLOW T O
COOL BEFORE REFUELING.
400268
WARNING
12 13
14
PARTS BAG & LITERATURE ASSY P/N 811201
ENGINE LABELS 15
READ OWNER'S MANUAL
BEFORE OPERATING, MAKE SURE:
USE PROTECTION
EXHAUST ELBOW IS ATTACHED.
EXHAUST IS DISCHARGING INTO
ENCLOSED CONTAINER.
ALL GUARDS ARE ATTACHED.
HOSE IS ATTACHED.
USE ONLY A QUALIFIED MECHANIC TO SER VICE THIS MACHINE.
INSPECT MACHINE BEFORE EACH USE AND REPLACE ANY
WORN AND DAMAGED PARTS.
ABRASIVE DEBRIS WILL SHORTEN UNIT LIFE.
830138
OPERATING INSTRUCTION IS OBTAINED.
STOP ENGINE AND ALLOW T O
COOL BEFORE REFUELING.
KEEP ENGINE CLEAN OF DEBRIS.
PROPERLY SECURE EQUIPMENT BEFORE TRANSPORTING.
NEVER SERVICE UNIT WITHOUT DISCONNECTING SPARK PLUG WIRE.
Label Caution
Item 47 Part No.830138
DANGER
810736
Label Danger Flying Material
Item No. 19 Part No. 810736
Briggs & Stratton Vanguard
FUEL SHUTOFF FUEL SHUTOFF
OFF
ON
ENGINE MAINTENANCE
1. CHECK OIL LEVEL
2. CHECK & CLEAN AIR CLEANER
3. CHANGE OIL
4. REPLACE OIL FILTER
5. CLEAN COOLING FINS 8 HOURS
25 HOURS
50 HOURS
100 HOURS
100 HOURS
See Operating and Maintenance Instructions
Honda
WHEN OIL LEVEL LOW,
ENGINE STOPS IMMEDIATELY.
OIL ALERT
Throttle Controls
SLO
W
F AST
STOP
START
Start
position
Stop
position
Honda
Units have
frame
mounted
throttle
controls as
shown
here.
Briggs Vanguard Units
have an engine mounted
throttle control.
Start
position
Stop
position
STOP
RUN
RUN
CHOKE
Engine
Stop
Switch
H O N D A M O T O R C O ., L T D . M A D E I N J A PA N
Chain Loop Assy
810878 Qty. 2
54
5
Nut Lock 5/16-18
8160002 Qty. 3
52
Nut Lock 1/4-20
8160001 Qty. 4
80
Screw Cap 5/16-18 x 1 1/2
8041030 Qty. 3
6
Washer 5/16 FLAT CUT
8171003 Qty. 1
79
Washer 5/16
Fender
8172020 Qty. 4
4
Washer 5/16 SAE
8172008 Qty. 4
55
Screw Cap 1/4-20 x 1 3/4
8041009 Qty. 2
Owner's
Manual
Literature
Parts Bag
Literature
HTR / TR
Accessories
Check Owner's
Manual
811202
Literature
Parts Bag
811203
Check
Literature
HTR / TR
Accessories
811208
Check
Warranty
Card
Check Warranty
Card
400972
Check EU Declaration
of Conformity &
EU Distributor
List 811204
EU Declaration
of Conformity
& EU
Distributor List
Literature Checklist
Label Ear Eye Breathing
Item No. 48 Part No. 890254
Label Read Owner's Manual
Item 15 Part No.830301
Briggs & Stratton
RUN CHOKE
ON
OFF
THIS ENGINE EQUIPPED WITH
LOW OIL SENSOR, IF ENGINE WILL
NOT START, CHECK OIL LEVEL
Read and follow Operating
Instructions before running engine.
Gasoline is flammable. Allow engine
to cool at least 2 minutes before fueling.
Engines emit carbon monoxide,
DO NOT run in enclosed area.
Clean debris from all engine surfaces
regularly to prevent engine overheating,
premature failure, or fire.
Label Warning Engine Overheat
Item 49 Part No.811215
