Billy Goat TR1104EU - Manual (Page 11)

Part No. 811237 Form No. F050304A
* Denotes standard
hardware item that may
be purchased locally.
Denotes parts found in
parts bag assembly.
19
Parts List
Page 11 of 12
1 FLAPPER 8" INTAKE W/ LABEL 811174 1 811174 1 811174 1
2 NUT LOCK 10-24 - - 8164005 2 8164005 2
3 LABEL DANGER KEEP HANDS AND FEET AWAY 400424 2 400424 2 400424 2
4 WASHER 5/16 SAE (11/32 ID x 11/16 OD x 1/16) *8172008 13 *8172008 11 *8172008 11
5 NUT LOCK 5/16-18 *8160002 22 *8160002 20 *8160002 20
6 WASHER 5/16 FLAT CUT (3/8 I.D. x 7/8 O.D. x 1/16) *8171003 47 *8171003 47 *8171003 47
7 PLUG 3/4" 811123 1 811123 1 811123 1
8 DEFLECTOR EXHAUST 7" 811111 1 811111 1 811111 1
9 CARRIAGE BOLT 5/16-18 x 3 1/2 *8024050 1 *8024050 1 *8024050 1
10 ELBOW ASSY TR/HTR 811191 1 811191 1 811191 1
11 GRIP HANDLE 3/4" ID 2" LONG BLACK 811233 1 811233 1 811233 1
12 TUBE CLAMP 810953 1 810953 1 810953 1
13 KNOB 400339 2 400339 2 400339 2
14 IMPELLER ASSY (INCLUDES 16(1),17(1),18(1), 20(1)) 810930 1 810974 1 810629 1
15 LABEL READ OWNER'S MANUAL 890301 1 890301 1 890301 1
16 SCREW CAP 3/8-24 x 2" GR 8 [50 Ft. Lbs. (68 N.m)] 810962 1 - - - - - - - - - -
SCREW CAP 3/8 - 24 X 2 1/4 GR 8 [50 Ft. Lbs. (68 N.m)] - - - - - 810932 1 - - - - -
SCREW CAP 7/16 - 20 X 2 GR 5 [60 Ft. Lbs. (81.4 N.m)] - - - - - - - - - - 500188 1
17 WASHER LOCK 3/8 TWISTED TOOTH 400502 1 400502 1 - - - - -
WASHER LOCK 7/16 TWISTED TOOTH - - - - - - - - - - 850132 1
18 KEY SQ. 1/4 x 2 3/4 *9201125 1 *9201125 1 - - - - -
KEY SQ. 1/4 X 2 1/4 - - - - - - - - - - *9201123 1
19 LABEL DANGER FLYING MATERIAL 810736 2 810736 2 810736 2
20 SPACER IMPELLER 830112 1 830112 1 830112 1
21 GUARD MANIFOLD 811059 1 - - - - - - - - - -
22 GUIDE STARTER ROPE (HALF) 830533 2 830533 2 830533 2
23 TUBE REAR FRAME 811218 1 811218 1 811218 1
24 COUPLER HOSE W/GRIP 811235 1 811235 1 811235 1
25 PAD FRAME SHORT 811120 2 811120 2 811120 2
26 CARRIAGE BOLT 5/16-18 x 2 1/4 *8024045 1 - - - - - - - - - -
CARRIAGE BOLT 5/16-18 x 4 1/2 - - - - - *8024054 1 *8024054 1
27 SCREW CAP 5/16-18 x 1 1/2 *8041030 4 *8041030 4 - - - - -
SCREW CAP 5/16-18 x 2 1/2 - - - - - - - - - - *8041034 4
28 ENGINE 18 H.P. VN W\CONTROL PANEL 811224 1 - - - - - - - - - -
ENGINE HONDA 13HP - - - - - 430366 1 - - - - -
ENGINE BRIGGS 11 HP INTEK I/C - - - - - - - - - - 811205 1
29 KNOB PLASTIC 5/15 NUT INSERT 850154 2 850154 2 850154 2
30 NUT LOCK W.A. 800227 2 800227 2 800227 2
31 WASHER 3/4, PLASTIC 800109 2 800109 2 800109 2
32 STUD 3/4 -10 x 5 1/2 810954 2 810954 2 810954 2
33 SCREW MACHINE #10-24 x 2 *8059143 2 *8059143 2 *8059143 2
34 PIN COTTER 1/8 x 1" *8197031 2 *8197031 2 *8197031 2
35 WASHER 3/8 SAE *8172009 4 *8172009 4 *8172009 4
36 NUT LOCK 3/8-16 *8160003 18 *8160003 18 *8160003 18
37 SCREW SHEET METAL 1/4 AB x 3/4 *8122082 3 - - - - - - - - -
38 GUARD MUFFLER 811058 1 - - - - - - - - -
39 BASE ENGINE 810907 1 810907 1 810907 1
40 PAD FRAME LONG 811122 2 811122 2 811122 2
41 PLATE FRONT 8" TR W/INTERLOCK (INCL. 1,2,3,5(2),7,13,43,44,49,59,83,84,87,88) 811234 1 811239 1 811239 1
42 PLUG CAP 1" SQUARE 810535 2 810535 2 810535 2
43 CABLE ASSY SWITCH SV 890442 1 890442 1 890442 1
44 CLIP-CABLE LIFT 850200 3 850200 3 850200 3
45 WASHER-1.5 OD X 0.531 ID 610308-P 2 610308-P 2 610308-P 2
46 SPRING COMPRESSION 400332 2 400332 2 400332 2
47 LABEL CAUTION 830138 1 830138 1 830138 1
48 LABEL EAR,EYE,BREATHING 890254 1 890254 1 890254 1
49 LABEL WARNING ENGINE OVERHEAT 811215 2 811215 2 811215 2
50 BOOM-PIVOT W.A. 810870 1 810870 1 810870 1
51 TUBE-SQUARE BOOM ARM 810875 1 810875 1 810875 1
52 NUT LOCK 1/4-20 *8160001 5 *8160001 5 *8160001 5
53 HOSE 8" x 12.5' TR (COMES IN SEPERATE BOX) 810523 1 810523 1 810523 1
54 CHAIN-LOOP ASSY 810878 2 810878 2 810878 2
55 SCREW CAP 1/4-20 x 1 3/4 *8041009 2 *8041009 2 *8041009 2
56 BAND HOSE BOOM 8" TR 810880 2 810880 2 810880 2
57 HOUSING ASSY W/LABELS (INCLUDES 35(2), 36(2), 45(2), 46(2), 47, 48, 90(2) 810912 1 810976 1 810976 1
58 NOZZLE ASSY 8" TR (INCL. 4(2), 5(3), 6, 23, 77, 79(4), 80(2), 82, 83, 84 811009 1 811009 1 811009 1
59 SPACER ENGINE INTEK - - - - - - - - 430355 1
60 CLAMP HOSE 8" TR 810566 2 810566 2 810566 2
61 ELBOW EXHAUST WA 811192 1 811192 1 811192 1
62 PAD FRAME CLAMP TUBE 811121 1 811121 1 811121 1
63 SUPPORT PLATE ENGINE / SPACER ENG. 810927 1 810965 1 810965 1
TR1104EU
PART NO.
QTY
HTR1803VEU
PART NO.
QTY
TR1304HEU
PART NO.
QTY ITEM DESCRIPTION
