Product Information
1 AXR-RF RF Receiver
Product Information
The AXR-RF Radio Receiver provides wireless reception of AMX radio frequency (RF)
transmitters. The AXR-RF connects to an Axcess Central Controller with an AXlink, 4-pin captive-
wire connector. When required for large areas, or multiple-room coverage, multiple receivers can
be connected in parallel on the AXlink bus.
Specifications
Power Consumption 780 mW; ±12 VDC, 65 mA (max.)
Dimensions (HWD) 1.5" x 5.09" x 5.27" (3.81 cm x 12.93 cm x 13.39 cm)
Weight 10.56 oz. (299.37 g)
Front Panel Components:
Radio data LED Red LED lights to indicate the AXR-RF has received an RF signal from an AMX
transmitter.
AXlink LED Green LED that lights to indicate AXlink power/data status as follows:
• One blink/second indicates power is active and AXlink communication is
working.
• Two blinks/second indicates the devices specified in the main program do not
match the devices found.
• Three blinks/second indicates there is an AXlink communication error
• Full on indicates there is either no AXlink control/activity (but the power is On)
or the Axcess program is not loaded.
Rear Panel Components:
AXlink connector 4-wire captive-wire AXlink connector for the Central Controller provides data
and nominal ±12 VDC power.
Device number 8-position DIP switch sets the device number for the AXR-RF.
RF antenna Receiving antenna screws into the TXC antenna connector. If it is necessary to
place the antenna in a remote position, use up to 6 ft. (2 m.) of RG-174 coax
cable as an extension. Extend the antenna vertically during use.
TXC antenna connector Antenna coaxial connector
Receive Frequency 418 MHz standard (other frequencies are available)
Maximum Range 300 feet (91.44 m)
Enclosure Molded black matte plastic
Options • Alternate frequencies available
• PS2.8 Power Supply
