AEG S63300KDW0 - Manual (Page 21)

2
1
• Remove the plugs on the upper side of
both doors and move them to the other
side
• Re-insert the lower door on the lower
hinge pivot .
• Insert the middle hinge into the left drill
of the lower door.
• Unscrew the upper hinge pivot and
place it on the opposite side.
• Fit the upper door on the upper door
pivot.
• Re-insert the upper door on the middle
hinge pivot slightly tilting both doors.
• Re-screw the middle hinge . Do not for-
get the plastic spacer .
A
C
B
• Remove the covers (B). Remove the
cover pins (A).
• Unscrew the handles (C) and fix them
on the opposite side.
• Re-insert the cover pins (A) on the op-
posite side.
Do a final check to make sure that:
• All screws are tightened.
• The magnetic seal adheres to the cabi-
net.
• The door opens and closes correctly.
If the ambient temperature is cold (i.e. in
Winter), the gasket may not fit perfectly to
the cabinet. In that case, wait for the natu-
ral fitting of the gasket.
In case you do not want to carry out the
above mentioned operations, contact the
nearest After Sales Service Force. The Af-
ter Sales Service specialist will carry out
the reversibility of the doors at your cost.
TECHNICAL DATA
Dimension of the recess
Height 1850 mm
Width 595 mm
Depth 658 mm
Rising Time 18 h
Voltage 230 - 240 V
Frequency 50 Hz
The technical information are situated in
the rating plate on the internal left side of
the appliance and in the energy label.
ENGLISH
21
