Chapter 3 31
Operation Verification
Checking the Output Power
NOTE
Limit values are due to power meter uncertainty.
Option 550 Option 567
Frequency Amplitude Limits Frequency Amplitude Limits
Option dBm dB Option dBm dB
60 GHz None 5 ±1.2 60 GHz None 5 ±1.2
1EA 14 ±1.2 1EA 14 ±1.2
1E1 3 ±1.2 1E1 3 ±1.2
1E1 & 1EA 10 ±1.2 1E1 & 1EA 10 ±1.2
67 GHz None 5 ±1.2 67 GHz None 5 ±1.2
1EA 12 ±1.2 1EA 12 ±1.2
1E1 3 ±1.2 1E1 3 ±1.2
1E1 & 1EA 10 ±1.2 1E1 & 1EA 10 ±1.2
Table 3-6 Leveled Output Power Limits, E8267D
E8267D
Option 520 Option 532 & 544
Frequency Amplitude Limits Frequency Amplitude Limits
Option dBm dB Option dBm dB
250 kHz None 15 ±0.6 250 kHz None 12 ±1.0
3.2 GHz None 15 ±0.8 3.2 GHz None 12 ±1.0
20 GHz None 18 ±0.8 20 GHz None 14 ±1.0
40 GHz None 12 ±1.0
44 GHz None 10 ±0.9
Table 3-5 Leveled Output Power Limits, E8257D cont.
