Chapter 3 29
Operation Verification
Checking the Output Power
Table 3-4 Leveled Output Power Limits, E8257D
E8257D
Option 520 Option 540
Frequency Amplitude Limits Frequency Amplitude Limits
Option dBm dB Option dBm dB
250 kHz None 13 ±0.6 250 kHz None 9 ±0.6
1EA 16 ±0.6 1EA 15 ±0.6
1E1 11 ±0.6 1E1 7 ±0.6
1E1 & 1EA 15 ±0.6 1E1 & 1EA 14 ±0.8
3.2 GHz None 13 ±0.8 3.2 GHz None 9 ±0.8
1EA 16 ±0.8 1EA 15 ±0.8
1E1 11 ±0.8 1E1 7 ±0.8
1E1 & 1EA 15 ±0.8 1E1 & 1EA 14 ±0.8
20 GHz None 13 ±0.8 20 GHz None 9 ±0.9
1EA 20 ±0.8 1EA 18 ±1.0
1E1 11 ±0.8 1E1 7 ±0.9
1E1 & 1EA 18 ±0.8 1E1 & 1EA 16 ±1.0
40 GHz None 9 ±0.9
1EA 14 ±1.0
1E1 7 ±0.9
1E1 & 1EA 12 ±1.0
