Using CentreWare Internet Services to Configure Settings on the Machine
Xerox CopyCentre/WorkCentre 118 System Administration Guide 97
2. In the [Properties] frame, select the plus symbol [+] to the left of the [Port Settings]
folder.
3. Select [USB].
4. Set up the following options to be displayed in the frame.
• Auto Eject Time
• Adobe Communication Protocol (Only available when the optional PostScript Kit is
installed.)
NOTE: For more information about the optionss, refer to Properties in the CentreWare
Internet Services chapter of the User Guide.
5. Select [Apply New Settings] to reflect the new setting.
6. Enter the user ID and password, then select [OK].
NOTE: The default user ID is "admin" and the default password is "x-admin".
7. When the reboot message appears, select [Reboot].
EtherTalk
This is only available when the optional PostScript Kit is installed. This page allows you
to configure the EtherTalk settings.
1. At the CentreWare Internet Services home page for the machine, select the
[Properties] tab.
2. In the [Properties] frame, select the plus symbol [+] to the left of the [Protocol
Settings] folder.
3. Select [EtherTalk].
4. Set up the following options to be displayed in the frame.
• Printer Name
• Zone Name
• Printer Type
NOTE: For more information about the options, refer to Properties in the CentreWare
Internet Services chapter of the User Guide.
5. Select [Apply New Settings] to reflect the new setting.
6. Enter the user ID and password, then select [OK].
NOTE: The default user ID is "admin" and the default password is "x-admin".
SMB (Microsoft Networking)
This page allows you to configure the SMB settings for the following options.
NOTE: Some settings on this page will only be available after you reboot the machine
from CentreWare Internet Services, or after the machine is switched off and on.
