Xerox WorkCentre M118-M118i-15205 - Manual (Page 54)

4 UNIX TCP/IP
54 Xerox CopyCentre/WorkCentre 118 System Administration Guide
Examples
• To inquire about the print data received by a printer named fxPS, enter the following
command:
%lpq -PfxPS
• To display a printer named fxPS in long format, enter the following command:
%lpq -PfxPS -l
-C Option
On SunOS, the -C option can be used to specify the print format if the machine prints
with the PostScript language in spool mode.
This section explains the functions which can be specified and printing operations
which will be affected using the -C option.
NOTE: When the PostScript logical printer that was configured using CentreWare
Internet Services and the -C option have been specified simultaneously, some of the
actions cannot be guaranteed to work. Also, when specifying the PostScript logical
printer as a default printer on UNIX, it is recommended not to use the -C option.
Function
The following items can be set up using the -C option.
Selecting a paper tray
When selecting a paper tray, specify either a paper size or a tray. If the paper size is
specified, the machine automatically searches and selects the tray.
The following parameters can be specified.
Parameter Description
INTRAY1/intray1 Selects Tray 1.
INTRAY2/intray2 Selects Tray 2 (optional).
INTRAY3/intray3 Selects Tray 3 (optional).
INTRAY4/intray4 Selects Tray 4 (optional).
INTRAY5/intray5 Selects Tray 5 (manual feed).
INMF/inmf Selects Tray 5 (manual feed).
A3/a3 Selects the tray which has A3 (297 × 420 mm/11.7 ×
16.5 inches) paper loaded.
B4/b4 Selects the tray which has B4 (257 × 364 mm/10.1 ×
14.3 inches) paper loaded.
A4/a4 Selects the tray which has A4 (210 × 297 mm/8.3 ×
11.7 inches) paper loaded.
