11 CentreWare Internet Services
100 Xerox CopyCentre/WorkCentre 118 System Administration Guide
• Get DNS Address
• DNS Address 1–3
• DNS Name
• Generate Domain Search List Automatically
• Domain Name 1–3
• Connection Time-Out
• Dynamic DNS Update
• Get WINS Server Address
• Primary WINS Server Address
• Secondary WINS Server Address
• IP Filter
NOTE: For more information about the options, refer to Properties in the CentreWare
Internet Services chapter of the User Guide.
5. Select [Apply New Settings] to reflect the new setting.
6. Enter the user ID and password, then select [OK].
NOTE: The default user ID is "admin" and the default password is "x-admin".
7. When the reboot message appears, select [Reboot].
LPD
This page allows you to configure the LPD settings for the following options.
NOTE: Some settings on this page will only be available after you reboot the machine
from CentreWare Internet Services, or after the machine is switched off and on.
1. At the CentreWare Internet Services home page for the machine, select the
[Properties] tab.
2. In the [Properties] frame, select the plus symbol [+] to the left of the [Protocol
Settings] folder.
3. Select [LPD].
4. Set up the following options to be displayed in the frame.
• Port Number
• TBCP Filter (Only available when the optional PostScript Kit is installed.)
• Connection Time-Out
NOTE: For more information about the options, refer to Properties in the CentreWare
Internet Services chapter of the User Guide.
5. Select [Apply New Settings] to reflect the new setting.
6. Enter the user ID and password, then select [OK].
