SIRMarine Owner’s Manual
About Sirius Satellite Radio 11 10 Use and Care/Troubleshooting/Specifications
AUDIOVOX Corp. strives to maintain and exceed the highest consumer standards. Due to these on going efforts, modifications
may be made from time to time to existing products without any prior notice. Specifications and appearance may differ from
those listed or shown in this manual. The Sirius name and related logos are trademarks of Sirius Satellite Radio, Inc. TERK and
TERK logo are trademarks of AUDIOVOX Corp.
About Sirius Satellite Radio
For more information about Sirius Satellite Radio service, visit their web site at:
www.siriusradio.com
Use and Care
In normal daily use, the TERK SIRMarine Satellite Radio Antenna is a rugged, high-performance
antenna that does not require any special attention.
Troubleshooting
Symptom Solutions
Sirius radio displays “Antenna” • Check antenna connections to the Sirius receiver.
or “Check Antenna” message
Sirius radio displays “No Signal” • Boat may be in an area where the Sirius signal is
message obstructed. Move the boat to more open surroundings.
Other symptoms • Call TERK for help at 1-800-942-TERK (8375) on
any business day, between 9
A . M . and 5:30 P . M ., EST
and ask for Technical Support.
Specifications
Electrical
Passive Satellite Antenna Element –
Frequency 2320.0 to 2332.5 MHz
Gain 4.5 to 7 dBi from 50 to 90 deg.
Bandwidth 12.5 MHz
Impedance 50 ohms
Polarization LHCP (Circular)
LNA for Satellite Signals –
Gain 33.5 dB, typical
Noise Figure 0.8 dB, maximum
Cable Loss -12.0 dB
Current Draw 160 mA, maximum
Output VSWR 1.5:1
Input P1dB -14
Mechanical
Total Height Deck Mount -1.08 inches
Mast Mount - 3.13 inches
Max Diameter 3.75 inches (outside)
Coax Cable 25 ft RG-174
Quality and Performance –
Temperature -40° to + 185° F (operating)
SIRIUS Approved Per SIRIUS Satellite Radio Specifications
